150 TON PNEUMATIC CLUTCH ENGAGED ECCENTRIC PRESS

150 Tons Pneumatic Clutch Engaged Eccentric Press 150 Tons Pneumatic Clutch Angling Eccentric Press Technical Specifications TYPE OF MACHINE HP 150 PK-AEP COURSE (STROKE) ADJUSTMENT 10-110 mm PULSE (STROKE) NUMBER OF STROKES 53 pcs/min. MORSE DIAMETER 50 mm MAXIMUM KNOB SHAFT LOWER RANGE 90 mm KNOB SHAFT MOVEMENT With Cr Cr System. RAM DIMENSION 420 x 250 x 560 mm TABLE DIMENSION 610X850 mm TABLE HOLE DIAMETER 200 mm DISTANCE BETWEEN TABLE CENTER AND BODY 300 mm DISTANCE BETWEEN TABLE AND COACH 450 mm ADDITIONAL DISTANCE BETWEEN JAMES AND TABLE 350 mm GRIP GRIP WORKING PRESSURE 6 bar 250 x 450 mm CRANKSHAFT STOPPING POINT Top dead center MAIN VOLTAGE 400 V – 3 phase – 50hz CONTROL VOLTAGE 24 V ELECTRONIC COUNTER Yes FUSE SYSTEM Mechanical Disc LUBRICATION SYSTEM Manual / Automatic (optional) GREASE USED GREASE TYPE 0-NUMBER CONDITIONER 10 PRESS HEIGHT 3100 mm PRESS DEPTH 1850 mm PRESS WIDTH 1500 mm APPROXIMATE WEIGHT 6000 kg ENGINE POWER 20 hp ENGINE SPEED 1400 r/d BODY STRUCTURE Steel Construction WORKING NOISE LEVEL dB PROTECTIVE ENGINE STRENGTH OF 2500 mm PROTECTION louver Optional ADJUSTABLE REVOLUTIONARY SYSTEM Optional MG Tool Tezgahları Makina San.Tic.Ltd.Şti Second Hand and New Machinery Purchase and Sale
