AT100 HEAVY DUTY LATHE

The ad is published in different categories. Ad content or information is incorrect. The specified ad / service has been rented or sold before. Other

E-mail Address

GSM

Subject

Message

Security Code

SEZGİNLER MAKİNA SAN TİC. AŞ.

3 Year

TÜRKİYE / BURSA

Store Page

Ad Details Technical Specifications

AT100 Heavy Duty Lathe Product Features Standard Accessories - Full Norton Clutch - 1000mm 4-Legged Mirror (with Shutter) - Cooling Water Hardware - Moving Lunet - Fixed Lunet - Lighting Lamp - Leveling Plate and Bolts - Tools and Tools Technical Specifications Diametermm1000 on the Counter Diamm1000 on the Trolleymm650 Diameter in Bridge Spacemm1500 Bench Widthmm755 Piece Weightkg5000 Distance Between Centers1-12 Spindle Hole Diameterm130 Spindle TaperA 15 Spindle Speed Pieces21 Spindle Speed Rangerev/min3.15-315 Main Motor PowerkW22 Longitudinal Advancement Rangemm/rev0.1-12 (56 pcs) Transverse Feed Rangemm/rev0.05-6 (56 pcs) Metric Threads mm1-120 (44 pcs) Inch ThreadsTPI3/8-28 (31 pcs) Module PitchModule0.5-60 (45 pcs) Diametric PitchDP1-56 (25 pcs) Trolley Transverse Movementimm520 Car Top Pencil Holder Movementm300 Opposite Tailstock Pinol Diameterm160 Opposite Tailstock Pinol TaperMK6 Opposite Tailstock Pinol Advance Amountm300
