DURAVIS Electric 2/2 U-PVC Ball Valve Voltage: 220VAC, 24VDC/AC Size: 1/2"...4" Way: 2/2 Way Body: Threaded/Adhesive, EPDM/VITON, U-PVC Operating Temperature: 55°C (U-PVC) Working Pressure: 16 bar (1/2"..2"), 10 bar (21/2"...3") Description: DURAVIS Electric Actuated U-PVC Ball Valves, one U They are automatic control valves consisting of a combination of a PVC ball valve and an electric actuator. Electric Valves; Since it provides a full pass, it eliminates the possibility of missing any particles in the line, clogging. BLV-P422 Series U-PVC ball valves are fully compatible with rotary electric actuators with the ISO5211 standard top flange on them. Body in harmony with the fluid; It can also be produced as UH-PVC, PVDF, PP or PPRC. It can also be offered as threaded connection instead of socket connection (adhesive connection). There are different voltage options and they can be controlled proportionally with a proportional electric actuator to be selected other than on-off. Model No / Order Coding: Model Size Road Voltage Working Pressure EAR-004-1111 & BLV-P422SE020M 1/2" (Ø20mm) 2/2 230V AC 0-16 Bar EAR-004-1111 & BLV-P422SE025M 3/4" (Ø25mm) 2/2 230V AC 0-16 Bar EAR-004-1111 & BLV-P422SE032M 1" (Ø32mm) 2/2 230V AC 0-16 Bar EAR-004-1111 & BLV-P422SE040M 1 1/4" ( Ø40mm) 2/2 230V AC 0-16 Bar EAR-004-1111 & BLV-P422SE050M 1 1/2" (Ø50mm) 2/2 230V AC 0-16 Bar EAR-006-1111 & BLV-P422SE063M 2" (Ø63mm) ) 2/2 230V AC 0-16 Bar EAR-006-1111 & BLV-P422SE075M 2 1/2" (Ø75mm) 2/2 230V AC 0-10 Bar EAR-008-1111 & BLV-P422SE090M 3" (Ø90mm) 2/2 230V AC 0-10 Bar EAR-008-1111 & BLV-P422SE110M 4" (Ø110mm) 2/2 230V AC 0-10 Bar EAR-004-1211 & BLV-P422SE020M 1/2" (Ø20mm) 2/ 2 24V DC/AC 0-16 Bar EAR-004-1211 & BLV-P422SE025M 3/4" (Ø25mm) 2/2 24V DC/AC 0-16 Bar EAR-004-1211 & BLV-P422SE032M 1" (Ø32mm) 2/2 24V DC/AC 0-16 Bar EAR-004-1211 & BLV-P422SE040M 1 1/4" (Ø40mm) 2/2 24V DC/AC 0-16 Bar EAR-004-1211 & BLV-P422SE050M 1 1 /2" (Ø50mm) 2/2 24V DC/AC 0-16 Bar EAR-006-1211 & BLV-P422SE0 63M 2" (Ø63mm) 2/2 24V DC 0-16 Bar EAR-006-1211 & BLV-P422SE075M 2 1/2" (Ø75mm) 2/2 24V DC 0-10 Bar EAR-008-1211 & BLV-P422SE090M 3" (Ø90mm) 2/2 24V DC 0-10 Bar EAR-008-1211 & BLV-P422SE110M 4" (Ø110mm) 2/2 24V DC 0-10 Bar *For threaded connection valve, code "B" instead of "S" . / Consult for proportional control. Technical Specifications (DURAVIS Electric Actuated U-PVC Ball Valves, Socket Connection, 2/2 Way) Control: On-Off (Optional: Proportional) Operating Voltage: 230V AC (24V DC on request) Valve Body: Full Bore, U-PVC , Muffed(Adhesive/Socket/Welded Connection) / Threaded on Request (double internal thread, single internal thread) Valve Dimensions: 1/2"(Ø20mm)...4"(Ø110mm) Valve Way/Port: Two Way Valve O-Ring/Bearing: EPDM or VITON Valve Working Temperature: -20°C …+130°C Usage Area: Water, acid, base and corrosive fluids etc. ball valve, ball valve prices,
