DURAVIS Electric 3/2 Gear Rust. Ball Valve Voltage: 220VAC, 24VDC/AC Size: 1/2"....4" Way: 3/2 Way (L or T port) Body: Threaded, Full Bore, AISI 304/316, Three Piece Operating Temperature: -50...210°C Working Pressure: PN63 Description: DURAVIS Electric Actuated Three Way Stainless Ball Valves are automatic control valves consisting of a combination of a 3/2 way stainless ball valve and an electric actuator. Since the energy source is electricity, they are used especially when the solenoid valve is not suitable for comparison. Electric Valves; Since it provides a full pass, it eliminates the possibility of missing any particles in the line, clogging. BLV-S232 Series stainless ball valves are fully compatible with rotary electric actuators with their ISO5211 standard top flange. BLV-S232 series are SS304 and can be manufactured from SS316 body upon request. There are different voltage options and they can be controlled proportionally with a proportional electric actuator to be selected other than on-off. Model No / Order Coding: Model Size Road Voltage Working Pressure EAR-004-1111 & BLV-S232BP015M 1/2" (DN15) 3/2 230V AC PN63 EAR-004-1111 & BLV-S232BP020M 3/4" (DN20) 3/2 230V AC PN63 EAR-004-1111 & BLV-S232BP025M 1" (DN25) 3/2 230V AC PN63 EAR-006-1111 & BLV-S232BP032M 1 1/4" (DN32) 3/2 230V AC PN63 EAR -006-1111 & BLV-S232BP040M 1 1/2" (DN40) 3/2 230V AC PN63 EAR-006-1111 & BLV-S232BP050M 2" (DN50) 3/2 230V AC PN63 EAR-004-1211 & BLV- S232BP015M 1/2" (DN15) 3/2 24V DC/AC PN63 EAR-004-1211 & BLV-S232BP020M 3/4" (DN20) 3/2 24V DC/AC PN63 EAR-004-1211 & BLV-S232BP025M 1 " (DN25) 3/2 24V DC/AC PN63 EAR-006-1211 & BLV-S232BP032M 1 1/4" (DN32) 3/2 24V DC PN63 EAR-006-1211 & BLV-S232BP040M 1 1/2" ( DN40) 3/2 24V DC PN63 EAR-006-1211 & BLV-S232BP050M 2" (DN50) 3/2 24V DC PN63 *Products with BLV-S232 code in the table; It is AISI 304 type. On request; AISI 316 ball valve body is recommended. Technical Specifications (DURAVIS Electric Actuated AISI 304 Stainless Steel Ball Valves, Threaded, 3/2 Way) Control: On-Off (Optional: Proportional) Operating Voltage: 230V AC or 24V DC/AC On-Off Time: It varies according to the model. (See technical catalogue). Output Torque: 40 Nm, 60 Nm (EAR-004, EAR-006) Protection Class: IP67 Ambient Temperature: -20°C...70°C Valve Body: Full Bore, SS304 Stainless Steel, Threaded BSP (On request ; NPT) Valve Dimensions: DN15...DN50 Valve-Actuator Selection: EAR-004 (DN15, DN20, DN25), EAR-006 (DN32, DN40, DN50) Valve Way/Port: Three Way (L port or T port) or Special Production Ball Option) Valve O-Ring/Bearing: PTFE Around the Globe and Throat O-Ring (two pieces) PTFE Valve Working Temperature: -50°C …+210°C Valve Working Pressure: PN 63 Usage Area: Gas or liquid flow control, tight shut-off valve against bubbles, mixing or diverting liquids and gases, directing the flow to different positions, by-passing the flow around the filter / flowmeter / heat exchanger, air dryer equipment, sterilizers, autoclaves, pollution control equipment, process control applications , laundry equipment, textile dyeing and drying, bottling and filling equipment, ink and dye distribution, etc. used in applications. ball valve, ball valve prices,
