DURAVIS Electric 3/2 Threaded Brass Ball Valve Voltage: 220VAC, 24VDC/AC Size: 1/2"....3" Way: 3/2 Way Body: Threaded, Full Bore, Brass, Two Piece Operating Temperature: -10 ...130°C Working Pressure: 40 bar (1/2"..11/4"), 16 bar (11/2"...3") Description: DURAVIS Electric Actuated Brass Ball Valves, a brass ball valve They are automatic control valves consisting of a combination of an electric actuator and an electric actuator. Since the energy source is electricity, they are used especially when the solenoid valve is not suitable for comparison. Electric Valves; Since it provides a full pass, it eliminates the possibility of missing any particles in the line, clogging. BLV-N132 Series brass ball valves are fully compatible with rotary electric actuators with their ISO5211 standard top flange. 3-way valves according to usage; They can be designed as L Port (distributing valve) and T Port (mixing valve). There are different voltage options and they can be controlled proportionally with a proportional electric actuator to be selected other than on-off. Model No / Order Coding: Model Size Road Voltage Working Pressure EAR-004-1111 & BLV-N132BP015M 1/2" (DN15) 3/2 230V AC 0-40 Bar EAR-004-1111 & BLV-N132BP020M 3/4" (DN20) 3/2 230V AC 0-40 Bar EAR-004-1111 & BLV-N132BP025M 1" (DN25) 3/2 230V AC 0-40 Bar EAR-004-1111 & BLV-N132BP032M 1 1/4" ( DN32) 3/2 230V AC 0-40 Bar EAR-006-1111 & BLV-N132BP040M 1 1/2" (DN40) 3/2 230V AC 0-16 Bar EAR-006-1111 & BLV-N132BP050M 2" (DN50) ) 3/2 230V AC 0-16 Bar EAR-004-1211 & BLV-N132BP015M 1/2" (DN15) 3/2 24V DC/AC 0-40 Bar EAR-004-1211 & BLV-N132BP020M 3/4" (DN20) 3/2 24V DC/AC 0-40 Bar EAR-004-1211 & BLV-N132BP025M 1" (DN25) 3/2 24V DC/AC 0-40 Bar EAR-004-1211 & BLV-N132BP032M 1 1 /4" (DN32) 3/2 24V DC/AC 0-40 Bar EAR-006-1211 & BLV-N132BP040M 1 1/2" (DN40) 3/2 24V DC 0-16 Bar EAR-006-1211 & BLV -N132BP050M 2" (DN50) 3/2 24V DC 0-16 Bar Technical Specifications (DURAVIS Electric Actuated Brass Ball Valves, Threaded, 3/2 Way) Control: On-Off (Optional: Proportional) Operating Voltage: 230V AC (Request on 24V D C) On-Off Time: It varies according to the model. (See technical catalogue). Output Torque: 40 Nm, 60 Nm (EAR-004 and EAR-006) Protection Class: IP67 Ambient Temperature: -20°C...70°C Valve Body: Full Bore, Nickel Plated Brass, Threaded BSP Valve Dimensions: DN15...DN80 Valve-Actuator Selection: EAR-004 (DN15, DN20, DN25, DN32, DN40), EAR-006 (DN50, DN65 and DN80) Valve Way/Port: Three Way Valve O-Ring/Bearing: Globe Surrounding PTFE and Throat O-Ring (two pieces) PTFE Valve Working Temperature: -20°C …+130°C Valve Working Pressure: PN 40(DN 15…DN32), PN25(DN40, DN65), PN16(DN 80) Usage Area: General purpose various industry applications ball valve, ball valve prices,
