DURAVIS EPV 100 Series Pulse Valves (3/4"-1"- Threaded) Usage Areas: Air Bag Filter, Bunker, Cement, Powder Coating etc. Way : 2/2 way Position: Normally Closed Body : Aluminum Sleeve : Stainless Steel Coil : 220/110/24/12 VAC, 24/12 VDC Description: DURAVIS EPV 100 Series Pulse Valves; It is generally used to transfer the particles accumulated in paint, cement, sand, dust collection systems, filter systems and lines used in these systems by working periodically. DURAVIS EPV 100 Series Pulse Valves are produced as single diaphragm or double diaphragm. Pulse solenoid valves with 3/4" and 1" connection sizes are single diaphragm. Pulse solenoid valves with large connection size such as 1 1/2" have double diaphragm. Double diaphragm valves are advantageous in terms of operation compared to single diaphragm valves. Inlet and outlet connections of DURAVIS Pulse Solenoid Valves form an angle of 90 degrees. The feature of sending compressed air in the form of pulse (shock) For this reason, these valves only work with compressed air and give this air pulse for a very short time. The permeability does not continue in the form of a pulse even if energized is continued. Therefore, they are operated by energizing for a short time at certain intervals. DURAVIS Pulse valves; normally closed It is a valve and it becomes open when it performs a shocking event by giving a pulse. Shocking occurs by giving an average of 100 ms energy. The shocking interval is set by the user. Since the pulse solenoid valves in the EPV 100 Series are mounted on the coil body, the dust filter system takes the control from the time relay, the time differential pressure relay It takes control of the system. It is possible to control sequential pulse valves with DURAVIS time relays (TIMER). These time relays; It is produced in a protective box with 8, 16, 24, 32, 40, 48, 56, 64 outputs, with adjustable pulse duration and waiting time interval. Model No / Order Coding: Model Size Road Voltage Min Pressure (bar) Max Pressure (bar) Min Temperature (C) Max Temperature (C) Sealing Approximate Weight (Kg) EPV 100-04 3/4" (DN20) 2/2 230/110/48/24/12 AC or DC 0.35 8.5 -40 +80 TPE 0.65 EPV 100-05 1" (DN25) 2/2 230/110/48/24/12 AC or DC 0.35 8.5 -40 +80 TPE 0.6 Technical Specifications (DURAVIS Pulse Solenoid Valves EPV 100, 3/4" and 1") Brand: DURAVIS Application: Dust Collection Systems Size: 3/4", 1" BSP (Option: NPT) Pressure: 0.35 bar...8.5 bar Sleeve, Core: Stainless Steel Body: Aluminum Diaphragm: TPE Temperature: -40°C…+80°C Position: Normally Closed Coil Voltage: 230, 110, 48, 24, 12V AC and DC Protection Class: IP65 Usage Area: Dust collector applications, especially reverse pulse jet filter cleaning and bag filters, cartridge filters, cassette filters, ceramic filters and sintered metal fiber filters, cement industry, ceramic industry , petrochemical industry, feed industry, sandblasting machines, energy and power plants, concrete plants etc. solenoid valve prices,
