DURAVIS ESV 403-404 Series Fuel Solenoid Valves (3/8"...1" Pilot Sand.)-High Pressure Usage Areas: Fuel Oil, Kerosene, Petrol etc. Way: 2/2 way Position: N.K. or N.A. Gasket : VITON (FPM) Body : Brass Sleeve : Stainless Steel Coil : 220/110/24/12 VAC, 24/12 VDC Description: DURAVIS solenoid valves to meet the demands of today's toughest applications; It safely controls fluids such as air, gas, water, oil and steam. ESV 403 (Normally Closed) and 404 (Normally Open Tube) series 2/2-way piston type fuel solenoid valves; Made with high quality materials such as brass, stainless steel. The closing element of these models is PTFE piston, and the magnetic field performance is maximized thanks to the stainless steel sleeve. These models with pilot control; It is produced in 1/8", 1/4", 3/8", 1/2", 3/4" and 1" sizes. Model No / Order Coding: Model Position Connection Size (G) Orifice Size Min Pressure AC (bar) Max Pressure AC (bar) Min Pressure DC (bar) Max Pressure DC (bar) Sealing ESV 403-02 N.K. 3/8" 12 mm 1 40 1 40 PTFE ESV 403-03 N.C. 1/2" 15 mm 1 40 1 40 PTFE ESV 403-04 N.C. 3/4" 20 mm 1 40 1 40 PTFE ESV 403-05 N.K. 1" 25 mm 1 40 1 40 PTFE ESV 403-02 N.A. 3/8" 12 mm 1 40 1 40 PTFE ESV 404-03 N.A. 1/2" 15 mm 1 40 1 40 PTFE ESV 404-04 N.A. 3/4" 20 mm 1 40 1 40 PTFE ESV 404-05 N.A. 1" 25 mm 1 40 1 40 PTFE ESV 403-00-120 N.C. 1/8" 12 mm 1 40 1 40 PTFE ESV 403-01-120 N.K. 1/4" 12 mm 1 40 1 40 PTFE ESV 404-00-120 N.A. 1/8" 12 mm 1 40 1 40 PTFE ESV 404-01-120 N.A. 1/4" 12 mm 1 40 1 40 PTFE *Please do not forget to specify the coil voltage when ordering! (230/110/48/24/12V AC or DC) Technical Specifications (DURAVIS ESV 403/404 Series 2/2 Way, Piston Type 1/8" .... 1" 40bar Fueloil Solenoid Valves) Application: Fuel oil, hot water, hydraulic oils, low viscosity oils, etc. Size: 1/8"......1" BSP (Optional: NPT) Pressure: 1 bar...40 bar Sleeve: Stainless Steel Body: Brass Sealing: PTFE Protection Class: IP65 Temperature: -10°C… +160°C Position: ESV 403 (Normally Closed) & ESV 404 (Normally Open) Voltage: 230, 110, 48, 24, 12V AC or DC Usage: Burners, mechanical pressure atomizers, turntables, compressed air, steam, gas oil etc. (Also, it can be used in some heavy fluids and corrosive fluids by consultation. solenoid valve prices,
