DURAVIS ESV 506 Compressor Solenoid Valves (1/8"-1/4" Direct Act.)-3/2 Way Usage Areas: Compressor, Filter, Dryer etc. Way : 3/2 way Position : N.K. Gasket : VITON (FPM) Body : Brass Sleeve : Stainless Steel Coil : 220/110/24/12 VAC, 24/12 VDC Description: DURAVIS ESV 506 3-way and direct operated solenoid valve is produced with threaded connection and VITON diaphragm. This valve has the ability to withstand a high pressure up to 16 bar and a high cycle due to the structure of the diaphragm. Thanks to the VITON diaphragm; It can also be used for hot water, alkaline oils, hydrocarbons and brine solutions. Model No / Order Coding: Model Position Connection Size (G) Orifice Size Min Pressure AC (bar) Max Pressure AC (bar) Min Pressure DC (bar) Max Pressure DC (bar) Sealing ESV 506-00-010 N.K. 1/8" 1 mm 0 16 0 16 VITON ESV 506-00-018 N.K. 1/8" 1.8 mm 0 12 0 12 VITON ESV 506-00-025 N.C. 1/8" 2.5 mm 0 6 0 6 VITON ESV 506-01-010 N.C. 1/4" 1 mm 0 16 0 16 VITON ESV 506-01-018 N.C. 1/4" 1.8 mm 0 12 0 12 VITON ESV 506-01-025 N.K. 1/4" 2.5 mm 0 6 0 6 VITON *Please do not forget to specify the coil voltage when ordering! (230/110/48/24/12V AC or DC) Technical Specifications (DURAVIS ESV 506 Series Direct Acting 1/8" and 1/4" Compressor Solenoid Valves) Application: Air, Gases etc. Size: 1/8" and 1/4" BSP (Optional: NPT) Pressure: 0 bar...16 bar Sleeve: Stainless Steel Body: Brass Sealing: VITON Temperature: -10°C…+160°C Position: Normally Closed Voltage: 230, 110, 48, 24, 12V AC or DC Protection Class: IP65 Application: Pilot valve in large diameter control valves, more oil and gas applications including offshore installations, single acting spring return pneumatic piston/cylinder general purpose applications such as control, compressor unloaders, turbines and lubricated air, inert gases, water, light oil... solenoid valve prices,
