JETCO / SGS-1020AHR SURFACE GRINDING

Technical specifications Unit SGS-1020AHR Working surface of the table mm 250X500 Maximum grinding surface mm 254X508 Maximum horizontal movement of the table mm 565 Maximum transverse movement of the table mm 263 Distance between the table surface and the spindle mm 500 Table speed meter/min 6~25 Automatic transverse feed of the seat mm 0~9 Vertical traverse (1 pitch) mm 0.01 Vertical traverse (1 turn) mm 2 Transverse traverse travel (1 pitch) mm 0.01 Transverse traverse (1 turn) mm 4 Linear traverse traverse setting mm 50~508 Transverse traverse traverse setting mm 0~254 Spindle motor HP 2 x 2P Hydraulic pump motor HP 1 x 6P Transverse feed motor HP 1/5 x 6P Down feed motor HP 1/5 x 6P Grinding wheel mm 205 x 13 x 31.75 Spindle speed rpm 2900 Coolant motor HP 1/8. Main collector motor HP 1/2 x 2P Net weight kg 1350 Gross weight kg 1600 Package dimensions mm 2060 x 1680 x 2050
