Working surface of the table mm 500X1500 Maximum grinding surface mm 500X1500 Maximum horizontal movement of the table mm 1650 Maximum transverse movement of the table mm 550 Distance between the table surface and the spindle mm 600 Table speed meters/minute 5~25 Automatic transverse advance of the seat mm 0~25 Vertical movement ( 1 pitch mm 0.002 Vertical travel (1 turn) mm 0.5 Transverse advance travel (1 pitch) mm 0.02 Transverse advance travel (1 turn) mm 5 Downward stroke micro-adjustment (1 pitch) mm AHD: 0.005 Downward stroke micro-adjustment ( 1 turn ) mm AHD: 0.05 Linear feed travel adjustment mm 150~1600 Transverse feed travel adjustment mm 0~510 Spindle motor HP 10 x 4P Hydraulic pump motor HP 5 x 4P Transverse feed motor HP 1/4 x 6P Down feed motor HP 1/2 x 4P Grinding wheel mm 405 x 50 x 127 Spindle speed rpm 1450 Coolant motor HP 1/8. Maximum load capacity kg 1200 Net weight kg 5000 Gross weight kg 5500 Package dimensions mm 4580 x 2280 x 2220
