Working surface of the table mm 600X1500 Maximum grinding surface mm 600X1500 Maximum horizontal movement of the table mm 1650 Maximum transverse movement of the table mm 650 Distance between the table surface and the spindle mm 600 Table speed meters/minute 5~25 Automatic transverse advance of the seat mm 0~25 Vertical movement ( 1 pitch mm 0.002 Vertical travel (1 turn) mm 0.5 Transverse advance travel (1 pitch) mm 0.02 Transverse advance travel (1 turn) mm 5 Downward stroke micro-adjustment (1 pitch) mm AHD: 0.005 Downward stroke micro-adjustment ( 1 turn ) mm AHD: 0.05 Linear feed travel adjustment mm 150~1600 Transverse feed travel adjustment mm 0~610 Spindle motor HP 10 x 4P Hydraulic pump motor HP 5 x 4P Transverse feed motor HP 1/4 x 6P Down feed motor HP 1/2 x 4P Grinding wheel mm 405 x 50 x 127 Spindle speed rpm 1450 Coolant motor HP 1/8. Maximum load capacity kg 1300 Net weight kg 6000 Gross weight kg 7000 Package dimensions mm 5180 x 2640 x 2300
