ST60160NC SURFACE GRINDING

The ad is published in different categories. Ad content or information is incorrect. The specified ad / service has been rented or sold before. Other

E-mail Address

GSM

Subject

Message

Security Code

SEZGİNLER MAKİNA SAN TİC. AŞ.

3 Year

TÜRKİYE / BURSA

Store Page

Ad Details Technical Specifications

ST60160NC Surface Grinding Product Features Standard Equipment - Y Axis Column Movement - Z Axis Head Movement - SIEMENS Electrical Materials - SIEMENS NC Touch Control System - Rigid Casting Body - Smooth and Easy to Maintain Spindle - 0.005mm Precision All Over the Table - Chip Programming Feature Standard Accessories - 2 Axis Digital Display - Lighting Lamp - Compact Control Panel - Automatic Lubrication - Grinding Wheel - Stone Balance Device - Stone Sharpening Pen - Stone Flange - Hydraulic Oil Tank - Magnetic Table - Magnetic Chip Scraper - Chip-Water Separation Device - External Hydraulic Unit Technical Specifications Table Dimensions (Width x Length x Height)mm600x1600 Magnetic Table Dimensionm600x1600 Spindle Distance Between Tablemm600 Loading Capacity of Tablekg1230 Longitudinal Advance Rangemm/min5-25 Diagonal Advancement Rangemm/tur1-30 Diagonal Rapid Advance Speedm/min0.05-2 Cross Hand Wheel Advancemm/range0.005 Vertical Auto Advancemm/tur0.005-0.05 Vertical Rapid Advancemm/min0.05-2 D Vertical Handwheel Advancemm/range0.005 Stone Speed mm/min960 Stone Sizem500x75x305 Stone Spindle MotorukW18.5 Weightkg8500
