Ad Details Technical Specifications

TG36A Gang Type CNC Lathe Product Features - Fanuc 0i-TF Plus 10.5" Operating System - Collet Type Hydraulic Chuck - Hydraulic Unit - 3 Colored Warning Lamp - Automatic Lubrication System - Belt Type Chip Conveyor and Trolley - Pencil Picker - 35mm - 2 Sets - Round Holder - 25mm Diameter - 2 Sets - Foot Pedal - Tool Case - Scale Feet - 2 Years Fanuc Warranty - 1 Year Mechanical Warranty Technical Specifications Maximum Turning Diametermm400 Maximum Turning Lengthmm300 Bar Capacitymm40 Chuck SizeInchClamp Spindle Motorukw5.5 Spindle Revolution/min4000 Work Spindle NormA2-5 Spindle Bearing Diam140 X Axis Movementm400 Z Axis Movementm300 X Axis Rapid Feed/min18 Z Axis Rapid Feed/d15 Slide TypeLinear Square Tool Sizem35 Round Tool Sizem25 Ground Requirement (LxL)mm2390x1530x1780 Weightkg2200
