YIDA EV-860 AND EV-1050 PROCESSING CENTERS

EV-860 and EV-1050 Vertical Machining Centers with Linear Bearing Slides produced by YIDA Precision Machinery are powerful machines that offer high precision, efficiency and durability for industrial processing needs and are offered with Fanuc 0i-MF and Mitsubishi M80A control unit options. These machines ensure superior results in industrial production processes with wide Octagonal movements, high speed cutting performance and long-life spindle.

product specifications:
Business Desk

EV-860: 1000x600 mm work table size, 600 kg carrying capacity
EV-1050: 1200x600 mm work table size, 600 kg carrying capacity
T-channels: 18x5x100 mm in size, suitable for installation
Octagonal Movements

X-axis (Longitudinal): 860 mm for Oct-860, 1050 mm for OCT-1050
Y-Oct (Transverse): 600 mm
Z-Oct (Vertical): 610 mm
Distance between the spindle forehead and the work table: 120~730 mm Dec
Distance between spindle axis and column Decking: 700 mm
Spindle

Engine Power: 15/11 kW (EV-860), 11/7,5 kW (EV-1050)
Speed: 10000rpm (8000/12000 optional)
ISO 40 Tool Shaft (compatible with BT-40 tools)
Inner Diameter: Ø70 mm spindle bearing diameter
Record Sled System and Speeds

Linear bearing slide system
Series movement speeds on X/Y/Z axes: 36/36/30 m/min
Cutting speeds: 1~10000 mm/min
Octax Servo Motors

Fanuc motor powers: on X/Y/Z axes 1,8/1,8/2,5 kW (Optional: 3,0/3,0/4,0 kW)
Mitsubishi engine powers: on X/Y/Z axes 2,0/2,0/3,0 kW
Team Magazine

Type: Sleeve type, can rotate in 2 directions
Tool holder shaft type: BT-40
Number of stations: 24
Maximum tool diameter: Ø80 mm
Maximum tool length: 300 mm
Maximum tool weight: 8 kg
Sensitivities

Positioning accuracy: ±0.005mm
Repetition accuracy: ±0.003mm
Dimensions and Weight

Net Weight: 6000 kg for EV-860, 6250 kg for EV-1050
Sizes:
EV-860: 3915 x 2570 x 2740 mm
EV-1050: 4301 x 2440 x 2724 mm
areas of use:
YIDA EV-860 and EV-1050 machining centers offer ideal solutions for industrial applications requiring high precision. These machines exhibit excellent performance in the automotive, aerospace, electronics and general machinery manufacturing sectors, metal processing, milling and various grinding processes.

Result:
YIDA Precision Machinery EV-860 and EV-1050 increase the efficiency in machining processes with their powerful motors, high precision Octagonal movements and large tool magazine capacity. The Fanuc and Mitsubishi control unit options offer operators flexibility and precision, providing the perfect solution for any industrial need.
