ENDÜSTRİYEL FANLI ISITICILAR

Technical data EH-60 EH-80 EH-100 Heating performance 60 kW (34,394 kcal) 80 kW (56,124 kcal) 100 kW (75,181 kcal) Air flow rate max 3,000 m³/h 3,500 m³/h 4,000 m³/h Air pressure 600 hPa Blow out temperature max.* 60 °C Temperature increase (∆T) max. 60 °C Fan radial / 2 kW radial / 3 kW radial / 4 kW Control   Four-stage switch for air flow rate and temperature Stufe 0 Air flow rate 3,000 m³/h 3,500 m³/h 4,000 m³/h Temperature increase (∆T) – Stage 1 Air flow rate 3,000 m³/h 3,500 m³/h 4,000 m³/h Temperature increase (∆T) 15 °C Stage 2 Air flow rate 3,000 m³/h 3,500 m³/h 4,000 m³/h Temperature increase (∆T) 28 °C Stage3 Air flow rate 3,000 m³/h 3,500 m³/h 4,000 m³/h Temperature increase (∆T) 40 °C Stage 4 Air flow rate 3,000 m³/h 3,500 m³/h 4,000 m³/h Temperature increase (∆T) 60 °C Input voltage 380 V-400 V / 50 Hz-60 Hz Power consumption max. 75 A (62 kW) 112 A (83 kW) 132 A (104 kW) Fuse protection / plug 78 A / CEE 78 A, 5-pin 115 A / CEE 115 A, 5-pin 135 A / direct connection Hose connection ø 450 mm 600 mm Suitable for hose lengths up to 100 m 100 m 100 m Mobility wheelable/ fork lift / crane
