TÜRKİYE / İZMİR
DIMENSIONS (Excluding Air Preparation Unit) Inner Outer Length (mm) 9000 9200 Width (mm) 4500 4620 Height (mm) 4000 4600 VENTILATION Fan Flow Rate (m3 / h) Engine Power (kw) Fresh Air Fan 18000 x 2=36000 5, 5 kw x 2=11 kw Exhaust Fan 18000 x 2=36000 5.5 kw x 2=11 kw Air velocity: 0.25 m3/h HEATING Fuel Type Diesel Burner Capacity (kcal/h) 250,000 kcal x 1 x LIGHTING Top Lighting 48 x 36 watts Side Lighting 42 x 18 watts ELECTRIC Lighting Power (W) 2484 W Total Power (kW) 30 Panel Electricity 380 V, 50 Hz. AIR FILTERS Ceiling Filters EU5 Pre-filters EU4 Floor Filters EU3 Exhaust Filters EU3 DOOR AND WALL Main Door (Material Inlet) mm 3100(W) x 3850 (H) Service Door (mm) 2 x 800(W) x 2127(H) Wall Thickness (mm) 50 Doors: In front of the cabinet, there is a 4-wing folding entrance door for material passage. Service Door: Personnel security There are also 2 Service entrance doors. All Doors have viewing windows made of safety glass. Burner Brand : Baltur Motor Brand : Volt - Gamak Fan Type : TRV Multiblade Heat Exchanger : Stainless Steel. Body 1.2 mm, faceplate Painting Temperature: 20-25 C Drying Temperature: 30-90 C Exproof Feature: None.
