POWERMAX 65 PLASMA UNIT

Powermax 65 General Information It is a Plasma Cutting Unit with Inverter Technology. Precise Amperage Adjustable with Feedback Electronic Technology and the amperage is not affected by ambient effects. Thanks to the latest technology and new generation Torch structure, it has a longer life consumable consumption compared to its competitors. Excellent results can be achieved in both thin material and thick material. Mains Voltage 400V / 50 - 60 Hz HZ The power drawn from the mains is 9 KW and the ampere drawn is 15.5 Amperes. Consumption Rates are quite low. Output Voltage is 139 VDC and 65 Amps. The On-Off rate is 50% at 65 Amps and 100% at 45 Amps. Open Circuit Voltage is Maximum 275 VDC. It measures 500 x 234 x 455 mm and weighs 26 KG. It only works with dry air or nitrogen. Capacity Thickness Cut Speed ​​Cut Recommended 20 mm (3/4") 500 mm/min (20 ipm) 25 mm (1") 250 mm/min (10 ipm) Side Entry 32 mm (1-1/4") 125 mm /min (5 ipm) Blasting 16 mm (5/8") Applications Hvac Line Red Line Specification Production Speed ​​ipm /min Black Steel 10 GA 3 65 224 6100 1/4 6 65 116 3240 3 / 8 10 65 62 1500 1/2 12 65 40 1140 5/8 16 65 26 650 10GA 3 65 296 8260 1/4 6 65 96 2850 3/8 10 65 52 1250 1/2 12 65 32 920 1/8 3 65 336 8800 1/4 6 65 152 4400 3 / 8 10 65 68 1650 1/2 12 65 48 1330
